50 Rockwell Automation Publication 750-TG100B-EN-P - June 2019

Chapter 3 Component Inspection and Test Procedures

Figure 6 - Frame 7 Power Module Power Terminal Locations

ID Connection ID Connection

1 +DC 3 R/L1, U/T1

2 –DC 4 S/L2, V/T2

5 T/L3, W/T3

1

2

5

4

3
