Rockwell Automation Publication 750-TG100B-EN-P - June 2019 73

Frame 5 Components Chapter 4

5. Install the filter capacitor in the reverse order of removal.

• Verify the placement of the resistor and new cable tie as shown here.

Wire Harness From Power

Circuit Board

Cable Tie Head

Resistor

Outside of

Chassis
