5
FW
P4.00
Fusibile 3A
Fuse 3A
Fusibile 20A
Fuse 20A
Fusibile 4A
Fuse 4A
Display a 4 cifre e 6 tasti di
programmazione
4 digit display and 6
programming buttons
Ingresso alimentazione
(secondario trasformatore)
Power supply unit
(transformer's secondary)
Morsettiere di
collegamento
periferiche
Device power
supply terminal
block
Microprocessore
CPU
Connettore scheda carica
batterie
Plug for battery charger
Collegamento batterie
Batteries connection
Collegamento
seriale RS485
RS485 serial
connection
Inverter a mosfet con
controllo sinusoidale
Mosfet inverter with
sinusoidal control
Collegamento
MOTORE
GEZSƼPM
MOTOR connection
(3 wiring cable)
Morsettiere dei
comandi
Commands terminal
blocks
Morsettiere delle
sicurezze
Safeties terminal
blocks
Connettori di collegamento
encoder, contatto di sblocco
e kit luci.
Plug for encoder, unlock
microswitch and lights kit
connection
Connettore ad innesto
per radio ricevente
Plug-in connector for
radio receiver
Connettore per
Applicazione WiFi
(USO FUTURO)
Plug-in for
WiFi Application
(FUTURE USE)
