Roger Technology CTRL Instruction And Warnings For The Installer

8
F2
PROG TEST
+
-
RECEIVER CARD
G
ER
ENC2
ENC1
LOCKS
LED LIGHT
COM
COM
+24V
+ES
+LAM
COM
COM
LNA
LNB
+SC
10 11 12 13 14 15 16 17 18 19 20
+LUCI
ST
COM
COS
FT
COM
ANT
21 22 23 24 25
COM
PED
PP
CH
AP
28 29 30 31 32
ORO
33
COM
3426 27
Bordo sensibile / Safety edge
STOP
Antenna
RG58 max 10 m
rosso/red
brown/red
marrone/rosso
blue/black
nero/black
blue/black
Apertura parziale / Partial opening
Passo passo / Step by step Chiusura / Closing Apertura / Opening Orologio / Timer
Lampeggiante / Flashing light
24Vdc 5W
Luci asta / Boom arm lights
24Vdc 12W
Spia stato barriera / Position barrier light
24Vdc 3W
Elettroblocco / Electric lock
12Vdc 10W (*)
Collegamento seriale RS485
RS485 serial connection
-
+
-
-
+
+
+
3
(*) Vmedia=12Vdc; Vmax=40Vdc (*) Vaverage=12Vdc; Vmax=40Vdc
