Rohde & Schwarz CMU 200 Service Manual

R&S CMU Troubleshooting
1100.4903.82 3.79 E-5
More troubleshooting
General errors on the transmitter side of the R&S CMU
Error description Troubleshooting to
Setting frequency in the module test faulty REFERENCE BOARD
MMCX cable W12
RXTX BOARD1
TR-CORRECTION MODULE1
MMCX cable W17
AUC MODULE1
TX DSP MODULE1
Setting frequency in the signalling test faulty UNIV. SIGN. UNIT
DIGITAL BOARD
Setting level in the module test faulty RF FRONTEND
SMA-cable W13
RXTX BOARD1
TR-CORRECTION MODULE1
MMCX cable W17
AUC MODULE1
TX DSP MODULE1
Setting level in the signalling test faulty UNIV. SIGN. UNIT
DIGITAL BOARD
Modulation in the module test faulty DIGITAL BOARD
AUC MODULE1
TX DSP MODULE1
Modulation in the signalling test faulty DIGITAL BOARD
AUC MODULE 1
UNIV. SIGN. UNIT
