Rohde & Schwarz CMU 200 Service Manual

R&S CMU Test Report
1100.4903.82 1.23 E-5
Test Report
ROHDE & SCHWARZ Universal Radiocommunication Tester R&S CMU 1100.0008
Serial number:
Test person:
Date:
Signature:
Table 1-2 Test report
Item
No.
Description
Measure-
ment
to section
Min. Actual Max.
Measurement
uncertainty
Unit
Ambient temperature during calibration 23 26 °C
General Tests
CONTINUOUS SELFTEST Passed passed
1 4/3 2 RF LOOP TEST Passed passed
Adjusting +5 V DC REFERENCE
VOLTAGE
Chapter 2 4.999 5.001 mV
Adjusting TCXO 10 MHz at
RF3 OUT 1 GHz
(if none of the options R&S CMU-B11
or R&S CMU-B12 is installed)
Chapter 2 –50 +50 Hz
Adjusting R&S CMU-B11 OCXO 10
MHz at RF3 OUT 1GHz
(if option R&S CMU-B11is installed)
Chapter 2 –10 +5 Hz
Adjusting R&S CMU-B12 OCXO 10
MHz at RF3 OUT 1GHz
(if option R&S CMU-B12 is installed)
Chapter 2 –10 +5 Hz
REF IN 52 MHz REF IN –1 +1 Hz
REF IN 1 MHz –1 +1 Hz
REF IN 10 MHz +50 Hz –1 +1 Hz
REF IN 10 MHz –50 Hz –1 +1 Hz
REF OUT 1 Int 10 MHz REF OUT 1 1.4 5 V(pp)
REF OUT 1 52 MHz 1.4 5 V(pp)
REF OUT 1 52 MHz –1 +1 Hz
REF OUT 1 1 MHz 1.4 5 V(pp)
REF OUT 1 1 MHz –1 +1 Hz
