Rohde & Schwarz CMU 200 Service Manual

Measuring Instruments and Auxiliary Equipment R&S CMU
1100.4903.82 1.2 E-5
Measuring Instruments and Auxiliary Equipment
Table 1-1 Measuring instruments and auxiliary equipment for manual performance test
Item Type of instrument Required characteristics Appropriate device R & S
order number
Use
1 Signal generator 100 kHz to 2.7 GHz,
Generation of a
GSM/CDMA2000/WCDMA
signal (dummy burst)
R&S SME03
R&S SMIQ03 with
options B42/B60
1038.6002.03
1125.5555.03
RX measurements
2 Spectrum analyzer 100 kHz to 7 GHz,
Demodulation of
GSM/CDMA2000/WCDMA
signals
R&S FSE with
R&S FSE-B7
R&S FSIQ-7 with options
B4/B5/B7/B11/B12/B70/
K71
R&S FSP–3
1066.3010.20/30
1119.5005.17
1164.4391.03
TX measurements
3 Power meter R&S NRVD with sensors
R&S NRV-Z4
R&S NRV-Z51
RX measurements,
TX measurements
4 Power amplifier 100 kHz to 2.7 GHz,
Pout = 100 W
RX measurements
5 Harmonics filter attenuate the harmonics of the
power amplifiers to min 30 dBc
RX measurements
6 Directional coupler 50 MHz to 2.7 GHz,
up to 100 W
RX measurements
7 Network analyzer
or VSWR Bridge
100 kHz to 2.7 GHz R&S ZVR
R&S ZRC
1043.0009.61 Reflection coefficient/
VSWR
RF connectors
