Rohde & Schwarz CMU 200 Service Manual

Für diese Unterlage behalten wir uns alle Rechte vor.
Ausgedruckte Dokumente unterliegen nicht dem Änderungsdienst.
For this document all rights are reserved.
Printed documents are not subject to revision
_
Pos.-Nr.
ItemNo
Menge
Quantity
ME
Unit
El.Kennz
Ref.Des.
Benennung / Bezeichnung
Designation
Z Sachnummer
Stock No.
Ersatzteil
Subst.part
BA VH
Benennung/Designation
ERSATZTEILE CMU
SPARE PARTS CMU
Sprach./Lang
de en
Ä.I. / C.I
18.00
Blatt/Sheet
1 of 12
Dokument Nr. / Document No.
1100.0114.01 ST
Datum/
Date
2006-06-19
Abt. /
Dept.
1CMK
Name /
Name
GL
ACHTUNG EGB/ATTENTION ESD
*VARIANTENERKLAERUNG
*EXPLANATION OF MODELS
VAR02=ERSATZTEILE CMU200
MOD02=SPARE PARTS CMU200
VAR03=ERSATZTEILE CMU300
MOD03=SPARE PARTS CMU300
VAR10=ERSATZTEILE CMU200/VAR10
MOD10=SPARE PARTS CMU200/MOD10
VAR30=ERSATZTEILE CMU200/VAR30
MOD30=SPARE PARTS CMU200/MOD30
VAR53=ERSATZTEILE CMU200/VAR53
MOD53=SPARE PARTS CMU200/MOD53
100 0 S A1 ZE FRONTMODUL Z 1090.9244.12 M
FRONT MODULE
Replaced by 1090.9244.22
101 0 S A1 ZE FRONTMODUL Z 1090.9244.22 M
FRONT MODULE
Replaced by 1090.9244.23
102 0 S A1 ZE FRONTMODUL Z 1090.9244.23 M O
FRONTMODUL
Replaced by 1090.9244.24
103 1 S A1 ZE FRONTMODUL Z 1090.9244.24 M O
FRONTMODUL
110 0 S A4 GR FMR5 VARIANTE 1091.2789.00 B A
FRONT MOD. CONTROLLER
included in 1090.9244.12
Replaced by 1091.2689.00
111 0 S A4 GR FMR5+ 1091.2689.00 B A
FRONT MOD. CONTROLLER
included in 1090.9244.12
Replaced by 1091.2720.00
120 0 S A4 GR FMR6/1 1091.2720.00 B G
FRONT MOD. CONTROLLER
included in 1090.9244.22
Replaced by 1091.2750.00
121 0 S A4 GR FMR6/2 1091.2750.00 B A
FRONT MOD. CONTROLLER
included in 1090.9244.22
Replaced by 1091.2808.00
122 0 S A4 GR FMR6/1+ 1091.2808.00 B A
FRONTMOD. CONTR. 6/1+
included in 1090.9244.23
Replaced by 1091.2814.00
123 1 S A4 GR FMR 6/1+ 1091.2814.00 B A
FRONTMOD.CONTR.6/1+
included in 1090.9244.24
130 0 S MZ WANNE Z 1090.9650.00 M
included in 1090.9244.12
131 1 S MZ RECHNERWANNE Z 1090.9421.00 M O
TUB
included in 1090.9244.22/23/24
140 0 S W17 DF DISPLAYVERBINDER 1091.0911.00 B O
CABLE
included in 1090.9244.12
Replaced by 1091.2620.00
141 0 S W17 GR DISPL.VERB.FMR6-SHARP 1091.2620.00 B G
DISPL.CONNECT FMR6-SHARP
included in 1090.9244.22/23
