Rohde & Schwarz CMU 200 Service Manual

Test Report R&S CMU
1100.4903.82 1.48 E-5
Options for R&S CR&S MU200: R&S CMU-K65 RX Analyzer WCDMA Demodulation
Item
No.
Description
Measurement
to section
Min. Actual Max.
Measurement
uncertainty
Unit
K65 RX WCDMA EVM rms
at 1920 MHz, Max level +25dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
2.5 %
K65 RX WCDMA I/Q Origin Offset
at 1920 MHz, Max level +25 dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
-55 dB
K65 RX WCDMA I/Q Imbalance
at 1920 MHz, Max level +25 dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
-30 dB
K65 RX WCDMA Carrier frequency
error
at 1920 MHz, Max level +25 dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
-10 10 Hz
K65 RX WCDMA Peak code domain
error
at 1920 MHz, Max level +25 dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
-40 dB
K65 RX WCDMA EVM rms
at 1980 MHz, Max level +25 dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
2.5 %
K65 RX WCDMA I/Q Origin Offset
at 1980 MHz, Max level +25 dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
-55 dB
K65 RX WCDMA I/Q Imbalance
at 1980 MHz, Max level +25 dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
-30 dB
K65 RX WCDMA Carrier frequency
error
at 1980 MHz, Max level +25 dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
-10 10 Hz
K65 RX WCDMA Peak code domain
error
at 1980 MHz, Max level +25 dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
-40 dB
K65 RX WCDMA EVM rms
at 1920 MHz, Max level +25 dBm,
input level +10dBm, RF 2
RX WCDMA
Demodulation
2.5 %
K65 RX WCDMA I/Q Origin Offset
at 1920 MHz, Max level +9 dBm,
input level +5dBm, RF 2
RX WCDMA
Demodulation
-55 dB
K65 RX WCDMA I/Q Imbalance
at 1920 MHz, Max level +9 dBm,
input level +5dBm, RF 2
RX WCDMA
Demodulation
-30 dB
K65 RX WCDMA Carrier frequency
error
at 1920 MHz, Max level +9 dBm,
input level +5dBm, RF 2
RX WCDMA
Demodulation
-10 10 Hz
K65 RX WCDMA Peak code domain
error
at 1920 MHz, Max level +9 dBm,
input level +5dBm, RF 2
RX WCDMA
Demodulation
-40 dB
