1. Introduction
1.1. Preface
Congratulations!
You have chosen a ROHDE sedimentation tank, a branded product that meets the highest demands and places
great value on quality.
This instruction manual is intended to simplify the use of your sedimentation tank for you. For this reason, all the
important information and guidelines you need have been summarised to enable you to use your work tool easily
and safely.
The basic requirement for safe working is compliance with all safety and handling instructions given in this manual.
1.2. Scope of delivery
Item Item description Quantity Remark
1
Three-compartment tank 1 piece
2
Base frame 1 piece
3
Castors 4 pieces
4
Trap 1 piece Including sealing plug
5
Flexible supply line 1 piece
Inflow connection from the sink
to the sedimentation tank
6
1 ½" to 1 ¼" reducer 1 piece
7
O-rings 1 ½" & 1 ¼" 1 of each
Optional
8
Cover for the AB 100 sedimentation tank 1 piece Item no. 657025
2. Product description
2.1. Technical characteristics
Property Description Remark
Model
AB 100 Sedimentation Tank
Volume
100 Litres
Sedimentation tank external
dimensions
630 mm x 450 mm x 520 mm W x D x H
Tank material
Polypropylene (PP) Easily recyclable plastic
Base frame material
Steel Robust & torsion-resistant
Inlet and outlet material
Polyethylene (PE) Easily recyclable plastic
Weight
13 kg
Special features
− Environmentally sound plastic tank
− Robust and shockproof
− 4 castors to make the tank mobile
− Optional cover available
