Rohde AB100 - Fitting the castors to the base frame

22 / 112 - EN -
5.3. Fitting the castors to the base frame
Step Description Illustration
1
Position the base frame (Item 2) so that the
4 threaded holes point upwards.
⇒ If necessary, carry out the work steps with
a second person.
⇒ Cover the floor if necessary to avoid
damage.
2
Screw the 4 castors (Item 3) into the base frame.
3
When tightening the castors:
Hold the hexagonal bolt with a 12 mm open-end
spanner.
4
As soon as the castors have been mounted, you
can turn the base around again and place it on
the castors.
⇒ If necessary, carry out the work steps with
a second person.
