23 / 112 - EN -
5.4. Position the three-compartment tank in the base
5.4.1. General safety information
Risk of personal injury and property damage!
The three-compartment tank and the base are not firmly attached.
5.4.2. Description
The castors (Item 3) must be firmly fitted to the
base (Item 2), which must stand on the 4
castors.
⇒ If necessary, carry out the work steps with
a second person.
⇒ Cover the floor if necessary to avoid
damage.
Position the three-compartment tank (Item 1) on
the base.
The base encloses the three-compartment tank,
which is loosely positioned and keeps it there.
When moving the entire sedimentation tank,
note that the three-compartment tank and the
base frame are not firmly attached.
