2. Product family
2.1. Ecotop
Model
(Volume)
T
max
(°C)
Internal
dimensions (mm)
External
dimensions (mm)
Power
(kW)
Current (A)
Connector &
Voltage
Furniture batts
(mm)
Weight (kg)
w
d
h
W
D
H
w
d
Ecotop 20
1300 Ø 330 228 645 685 564 2,3 10
Schuko
230 V
Ø 290 52
Ecotop 43
1300 Ø 400 342 739 728 660 2,9 13
Schuko
230 V
Ø 350 75
Ecotop 43 S
1320 Ø 400 342 739 728 660 3,6 16
Schuko
230 V
Ø 350 75
Ecotop 60
1300 Ø 400 456 755 728 782 3,6 16
Schuko
230 V
Ø 350 86
Ecotop 60 S
1320 Ø 400 456 755 728 782 5 7,5
CEE 16A
400 V
Ø 350 86
Not with supplementary ring for extension Special voltage electric supply for all EU networks available on request
and non dismantable
2.2. TE S (with ZWR)
Model
(Volume)
T
max
(°C)
Internal
dimensions (mm)
External
dimensions (mm)
Power
(kW)
Current (A)
Connector &
Voltage
Furniture batts
(mm)
Weight (kg)
w
d
h
W
D
H
w
d
TE 80 S
1320 Ø 450 460 790 800 780 6 13
CEE 16A
400 V
Ø 410 99
TE 95 S
1320 Ø 520 460 850 860 790 7,3 16
CEE 16A
400 V
Ø 470 113
TE 100 S
1320 Ø 450 610 790 850 930 9 13
CEE 16A
400 V
Ø 410 117
TE 130 S
1320 Ø 610 460 930 930 790 8,8 19
CEE 32A
400 V
Ø 540 130
TE 145 S
1320 Ø 520 680 850 910 1020 11 16
CEE 16A
400 V
Ø 470 142
TE 165 S
1320 730 630 460 1050 930 790 10 22
CEE 32A
400 V
Cut to size 144
TE 200 S
1320 Ø 610 680 930 990 1020 13,2 19
CEE 32A
400 V
Ø 540 166
TE 250 S
1320 730 630 680 1050 980 1020 15 22
CEE 32A
400 V
Cut to size 180
TE 300 S
1320 840 640 680 1060 950 1020 15 22
CEE 32A
400 V
Cut to size 204
ZWR TE 80 S
1320
Ø 450
150
790
800
150
3
-
-
-
ZWR TE 95 S
1320
Ø 520
230
850
860
230
3,7
-
-
-
ZWR TE 130 S
1320
Ø 610
230
930
930
230
4,4
-
-
-
ZWR TE 165 S
1320
730
630
230
1050
930
230
5
-
-
-
ZWR = Supplementary ring for extension Special voltage electric supply for all EU networks available on request
(TE 80/95/130/165 S)
