Roland cakewalk A-300PRO

29
Using A-PRO Editor
Here’s how to assign a MIDI message to each controller.
fig.editor-assign1.eps
1 In the main window, click the
controller to which you want to
assign a MIDI message.
fig.editor-assign2.eps
2 In the message assignment
window, use the Assign Message
field to select the type of MIDI
message you want to assign.
fig.editor-assign3.eps
3 According to the type of MIDI
message you selected, use the
fields of the message assignment
area to specify the parameters.
For details on the parameters, refer to
“Message Parameters” (p. 33).
fig.editor-assign4.eps
4 In the Output Port field, specify
the MIDI output port.
5 If desired, enter a name in the
Name field.
6 Click [OK].
Using Control Maps
Assigning MIDI Messages
