35
Using A-PRO Editor
Channel Message
Program Change (Min-Max)
Assign a program change message (with a variable
program number).
fig.editor-pcmm.eps
Specify the following parameters.
* The range of the program number is 1–128.
Bank Select + Program Change
Assign a bank select message and program change
message (all values fixed).
fig.editor-bankpc.eps
Specify the following parameters.
* The range of the program number is 1–128.
Program Change – Dec
Assign the program change decrement function (PC
DEC).
This will transmit a program change number that is one
less than the program change number most recently
transmitted in the A-PRO’s program change mode.
fig.editor-pcdec.eps
Item Content
MIDI Channel MIDI channel
Min Number Lower limit of the program number.
Max Number Upper limit of the program number.
Item Content
MIDI Channel MIDI channel
Bank MSB Bank number MSB
Bank LSB Bank number LSB
PC Number Program number
A-300_500_800C_e.book 35 ページ ２０１０年２月２２日 月曜日 午後９時１３分
