34
MIDI Implementation
7 POLY (Controller number 127)
Status 2nd byte 3rd byte
BnH 7FH 00H
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
9
System Realtime Messages
7 Active Sensing
Status
FEH
* This message is transmitted at intervals of approximately 250 msec.
7 System Exclusive Messages
Status
F0H :System Exclusive
F7H : EOX (End of Exclusive)
Transmitted in the following three cases.
1. When Operating Bulk-Dump
2. If Exclusive of System MIDI is “P-Dump, this unit transmits all parameters in the patch when the
patch is changed.
3. If Exclusive of System MIDI is TxEdit, this unit transmits the parameter when the parameter is
edited.
Refer to Section 3 to see details.
2. Receive data
9
Channel Voice Messages
7 Note o
Status 2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
n = MIDI channel number: 0H - FH (ch.1 - ch.16)
kk = note number: 00H - 7FH (0 - 127)
vv = note o velocity: 00H - 7FH (0 - 127)
7 Note on
Status 2nd byte 3rd byte
9nH kkH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
kk = note number: 00H - 7FH (0 - 127)
vv = note on velocity: 01H - 7FH (1 - 127)
7 Control Change
6
Bank Select (Controller number 0, 32)
Status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n = MIDI channel number: 0H - FH (ch.1 - 16)
mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* The Patches corresponding to each Bank Select are as follows.
BANK SELECT
USER/PRESET
BANK
PROGRAM
NUMBER
PATCH
NUMBER
MSB LSB
087
000 U1 1–64 11–88
001 U2 1–64 11–88
002 U3 1–64 11–88
003 U4 1–64 11–88
004 U5 1–64 11–88
005 U6 1–64 11–88
006 U7 1–64 11–88
007 U8 1–64 11–88
008 P1 1–64 11–88
009 P2 1–64 11–88
010 P3 1–64 11–88
011 P4 1–64 11–88
012 P5 1–64 11–88
013 P6 1–64 11–88
6
Modulation (Controller number 1)
Status 2nd byte 3rd byte
BnH 01H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Modulation depth: 00H - 7FH (0 - 127)
6
Portamento Time (Controller number 5)
Status 2nd byte 3rd byte
BnH 05H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Portamento Time: 00H - 7FH (0 - 127)
