Installing the Ink Cartridges
11
1. Changes to the Setup Guide1. Changes to the Setup Guide
10. When this screen appears, make sure the drain bottle is installed, and press .
CHECK
ẅDRAIN BOTTLE
Cleaning is nished.
Go on to “3. Insert the ink cartridges for the respective colors.” (p. 12)
2.Clean the print heads using the SOL INK cleaning cartridge (LEF-12)
1.
Press to select the ink type.
Ink type Display screen
EUV ink
SELECT INK TYPE
ECOUV CMYKGlW
EUV3 ink
SELECT INK TYPE
ECOUV3 CMYKGlW
2. Make sure the drain bottle is installed, and press .
INSTALL
DRAIN BOTTLE
3. Insert cleaning cartridges into displayed slots numbers.
1 2
SET CL-LIQUID
4. Insert dummy cartridges into displayed slots numbers, and press .
SET DUMMY CRT.
SLOT: 3,4
FILLING INK...
5. When this screen appears, pull out the cleaning cartridges.
REMOVE CL-LIQUID
1 2
