13
Chapter 1 Getting Started
1-1 About the Machine
Head (MPH-90)
Printing is performed on material using with a
marking pin. Diamond is attached to the tip of
the marking pin. Since the head is a consumable
part, replace it at an appropriate timing.
P. 52, “Head Replacement”
Material Retainers
Vise
This is used to x an instrument to be imprinted.
P. 35, "STEP 1: Loading the Instrument to be Im-
printed"
Table, Adhesive sheet
This is used to x an instrument to be imprinted
that cannot be secured using the vise. The adhesive
sheet is placed on the table and then the instrument
is placed on the sheet. This makes you to x the ob-
jects without having to use commercially available
tape or the like.
P. 35, "STEP 1: Loading the Instrument to be Im-
printed"
Marking pin
To Next Page
