16
Creating a Kit
PAD COMP settings
Parameter Value Explanation
ON/OFF ON, OFF Turns the pad compressor on/o.
TYPE
KICK 1, KICK 2,
SNARE 1,
SNARE 2, TOM 1,
TOM 2,
CYMBAL 1,
CYMBAL 2,
SOFT COMP,
HARD COMP,
LIMITER
Type of compressor
* Changing this parameter sets the pad compressor’s Ratio, Knee, Attack, and Release parameters
to optimal values. Based on these settings, you can adjust the value of each parameter as
necessary.
Gain -24.0–+24.0dB Compressor output volume
Thre -48–0dB Volume level at which compression starts
Ratio
1:1, 2:1, 3:1, 4:1, 8:1,
16:1, 32:1, 100:1
Compression ratio
Knee
HARD, SOFT1,
SOFT2, SOFT3
Attack of the sound at the moment compression is applied
Attack 0.1–100ms Time until compression starts
Release 10–1000ms Time until compression returns to the original state
PAD MUTE GROUP and PAD LINK settings
1. From the [OTHER] button items, select PAD MUTE
GROUP or PAD LINK, and press the [ENTER] button.
2. Press the [ENTER] button once again.
To cancel a specied mute/link, use the [K][J] buttons to select
“RESET,” and then press the [ENTER] button.
3. Use the [K][J] buttons to specify the group
number.
Up to eight groups can be specied.
4. Strike a pad to select the pad that you want to mute
or link.
PAD1–8 EXTERNAL TRIGGER INPUT 1–4
* For EXTERNAL TRIGGER INPUT 1–4, the upper row is HEAD and the
lower row is RIM.
MEMO
5 You can’t assign the same pad to dierent groups. If you attempt
to specify this, the following message appears.
5 You can’t use Pad Link to assign three or more pads to the same
group. If you attempt to specify this, the following message
appears.
