Roland OCTAPAD SPD-20 PRO User Manual

33
Specications
Pads
Built-in Pads: 8
* Four external trigger inputs are provided, allowing you to connect Pads.
Instruments Instruments: 900 instruments or greater
Kits 200 (Preset: 100)
Kit Chain 16 chains (16 steps per chain)
Layer
2 layers per pad
2 layers x 2(Head/Rim) per external Trigger
Instrument /Pad Parameters
Volume
Curve
Coarse Tune
Fine Tune
Pedal Bend
Decay
Output
Layer EQ
Pad comp
Pad Mute Group
Pad Link
Kit Eects
Ambience (5 Types)
Kit EQ
Kit Comp
MFX: 3 systems, 38 types
Display
16 characters 2 line (backlit LCD)
7 segments, 3 characters (LED)
Connectors
PHONES Jack: Stereo 1/4-inch phone type
OUTPUT(L/MONO, R) Jacks: 1/4-inch phone type
MIX IN Jack: Stereo 1/4-inch phone type
EXTERNAL TRIGGER INPUT Jack: 1/4-inch TRS phone type x 4
HH CTRL Jack: 1/4-inch phone type
FOOT SW Jack: 1/4-inch TRS phone type
MIDI (IN, OUT) Connectors
USB MEMORY port: USB A type
Power Supply AC adaptor (DC 12 V)
Current Draw 500 mA
Dimensions
450(W) x 350 (D) x 72 (H) mm
17-3/4 (W) x 13-13/16 (D) x 2-7/8 (H) inches
Weight 3.7 kg / 8 lbs 3 oz (excluding AC Adaptor)
Accessories
Owner’s Manual
AC Adaptor
Options (sold separately)
Pads (PD series, PDX series, BT series)
Cymbals (CY series)
Kick Triggers (KD series)
Hi-Hats (VH-11/10)
Hi-Hat Control Pedal (FD series)
Pad Stand (PDS series)
All-Purpose Clamp (APC series)
Acoustic Drum Trigger (RT series)
Footswitch (FS series)
Personal Drum Monitor (PM series)
* This document explains the specications of the product at the time that the document was issued. For the latest information, refer to the
Roland website.
