19
Creating a Kit
KIT EQ settings
Parameter Value Explanation
ON/OFF ON, OFF Turns the KIT EQ on/o.
LoFrq 20Hz–1kHz Species the center frequency of the low-frequency region.
LoGain -12–+12dB Amount of low-frequency boost/cut
MidFrq 20Hz–16kHz Adjusts the center frequency of the mid-frequency region.
Mid Q 0.5–8.0
Width of the mid-frequency region
Higher values make the region narrower.
MidGain -12–+12dB Adjusts the amount of mid-frequency boost/cut.
HiFrq 1–16kHz Species the center frequency of the high-frequency region.
HiGain -12–+12dB Adjusts the amount of high-frequency boost/cut.
KIT MIDI settings
Parameter Value Explanation
Note#
0 (C -)–127 (G 9)
MIDI note number transmitted/received for each pad
* If you specify a note number that is the same as the note number specied for a dierent pad,
an “*” is shown at the end.
OFF Note messages are not received or transmitted
GateTime 0.1– 8.0s Duration of the note that each pad transmits
Channel
CH1–CH16 MIDI channel used by each pad to transmit or receive note messages or control change messages
GLOBAL Transmit/receive using the transmit/receive channel specied in SYSTEM (p. 26)
HClNote (*)
(Hi-Hat Closed Note)
0 (C -)–127 (G 9), OFF MIDI note number transmitted and received for the closed hi-hat
HPedal (*)
(Hi-Hat Pedal)
0 (C -)–127 (G 9), OFF MIDI note number transmitted and received for the pedal hi-hat
INITIALIZE Returns the KIT MIDI settings to their factory-set state.
(*) Valid only for the pad that is controlled by hi-hat open/closed (p. 25).
