V-800HD Version 1.50 Added Functions
The following features were added to V-800HD version 1.50.
For information about version1.50 software, download from the following Roland website.
http://www.rolandsystemsgroup.net/
Supports 3G-SDI Level B Mapping Structure
• The V-800HD ver. 1.5 supports level B mapping structure of 3G-SDI (1080p50Hz, 1080p59.94Hz).
• The 3G-SDI mapping structure of the input signal is detected automatically.
• The mapping structure of 3G-SDI output signal can be selected using the menu.
Sync with Input Video Signal
• The V-800HD ver. 1.50 can synchronize with SDI input as reference.
• You can select a reference SDI input.
• The output vsync of the V-800HD synchronizes with the input signal when the value of System -> Reference is Input SDI 1, ...
Input SDI 4. In this case, the system latency is minimized. If you want to synchronize the input/output fields, execute the settings
below.
Field Sync Processing
• While the V-800HD input/output interlaced signals, synchronization of fields is possible.
A/B Mode Switching
• You can select A/B mode for video switching.
• PGM/PST is the default mode.
• Regardless to the PGM section or PST/EFFECT section of cross-points, PGM is determined by the video fader position. The
indicator of the PGM output channel lights in red. The indicator of the PST output channel lights in green.
• While you are compositing images, the indicator of background channel lights in red. The indicator of foreground channel lights
in green.
Menu Items Setting Value
Output -> Format Main -> 3G-SDI Mapping Level A, Level B
Menu Items Setting Value
System -> Reference Internal, External, Input SDI 1, ... Input SDI 4
Turn the Field Sync Processing of System to ON
Although the processing time increases, the input/
output fields match automatically.
Adjust the value of Reference Line Adjust in System
Although the input/output phases differ, you can
minimize the latency keeping the synchronization
of input/output fields.
Menu Items Setting Value Explanation
System -> Field Sync Processing
ON
Enables the field sync processing.
The fields of input/output match and this
improves the image quality.
However, the processing time increases.
OFF
Menu Items Setting Value
System -> Panel Operation PGM/PST, A/B
