Roland VR-3 - Appendices and Support Information

48
Appendices
fig.spec-sheet_E.eps
In the interest of product improvement, the specifications and/or appearance of this unit are subject to change without prior notice.
The VR-3 can be operated remotely from an external MIDI device. For more information about remote control, download the
separately available reference document from the following Roland website.
http://www.roland.co.jp/solution/
fig.MVC-logo.eps
The VR-3 can be operated remotely from a device that supports MIDI Visual Control. MIDI Visual Control is a feature that uses MIDI
to link visual expression to a musical performance.
Main Specifications
About Remote Control
Output Level and Impadance
Video
Audio Output
Impedance
Final Out : 1 k ohms
PHONES : 10 ohms
Audio
Output
Level
- 10 dBu, Max Output Level : + 8 dBu
Final Out
25mW + 25mWPHONES
1.0 Vp-p, 75 ohms
Others
DC 9 V (AC adaptor)
Power Supply
1.5 A
Current Draw
302 (W) x 208 (D) x 75 (H) mm
11-15/16 (W) x 8-3/16 (D) x 3 (H) inches
Dimensions
2.0 kg / 4 lbs 7 oz
Weight (excl. AC adaptor)
AC adaptor and power cord,
USB cable (A type - B type) x 1,
Owner's manual
Accesories
Input Level and Impadance
PC-RGB
1.0 Vp-p, 75 ohms
0.7 Vp-p, 75 ohms (H, V:5VTTL)
Video
Audio Input
Impedance
XLR/TRS : 4 k ohms
RCA/PC INPUT : 15 k ohms
Audio
Input
Level
- 68 to + 4 dBu
Max Input Level : + 22 dBu
XLR/TRS
-10 dBu, Max Input Level : + 8 dBuRCA
-15dBu, Max Input Level : + 3 dBuPC INPUT
Effects
Video
Cut, Mix, Wipe
Transition
Luminance Key, Chroma Key,
Picture in Picture, Split
Composition
Video Processing
Format
Sampling
Frame Synchronizer
NTSC/PAL (ITU601)
13.5 MHz, 4:2:2 (Y:R-Y:B-Y), 8 bits
Built-in x 4
800 x 600/120 Hz, 832 x 624/75 Hz,
1024 x 768/80 Hz,1152 x 864/75 Hz,
1152 x 870/75 Hz,1280 x 720/60 Hz,
1280 x 768/75 Hz, 1280 x 800/75 Hz,
1280 x 1024/75 Hz, 1366 x 768 /75 Hz
(RGB VH : Positive Logic/Negative Logic)
* Conforms to VESA DMT Ver 1.0 Revision 10
* The refresh rate is the maximum value of each resolution.
Video
PC-RGB
Audio Processing
Sampling 24 bits / 48 kHz
Other Connectors
Remote Control
MIDI IN (5 pin DIN type) x 1
MIDI OUT/THRU (5 pin DIN type) x 1
B type x 1
* Supports USB 2.0 Hi-Speed
USB
320 x 240 dotes
TFT color touch screen
Display
Input Connectors
Video
PC-RGB
Composite (RCA pin type) x 4
HD DB-15 type x 1
Audio
XLR/TRS combo type x 4
RCA pin type x 1 pair (L/R)
Stereo mini type x 1
Built-in stereo mic x 1 pair (L/R)
* If video is simultaneously input to Ch 4, PC-RGB takes priority.
Output Connectors
Video
Composite (RCA pin type) x 2
Audio
Standard type x 1 pair (L/R)
RCA pin type x 1 pair (L/R)
Final Out
Preview
Composite (RCA pin type) x 1
Final Out
PHONES
Standard type x 1, Stereo mini type x 1
PC-RGB (Thru out) HD DB-15 type x 1
Audio
High Pass, Noise Gate, EQ (Hi/Lo)
Input
Noise Suppressor, Enhancer,
Master (Hi/Lo), Audio Delay,
Reverb
Output
