Quick reference of displays
XP-80 displays are configured based on the following structure. To call up the display you desire, press the relevant buttons as
follows:
❚
Patch mode [PATCH]
Play display
Pressing [F1] (Common)
Playing a Patch (p.26)
[F1] (General) Naming a Patch and setting its volume level, panning, etc. (p.46)
[F2] (Control) Setting Key Assign, Portamento, etc. (p.47)
[F3] (Struct) Setting how Tones are combined (structure) (p.49)
[F4] (K.Range) Setting the keyboard range (p.50)
[F5] (V.Range) Setting the velocity range (p.50)
Pressing [F2] (WG)
[F1] (WG Prm) Setting Wave, Tone delay, etc. (p.51)
[F2] (Pitch) Setting the pitch (p.52)
[F3] (Pch Env) Setting the pitch envelope (p.53)
Pressing [F3] (TVF)
[F1] (TVF Prm) Modifying sound's brightness using a filter (p.54)
[F2] (TVF Env) Setting the TVF envelope (p.54)
Pressing [F4] (TVA)
[F1] (TVA Prm) Setting volume level, panning, etc. of each Tone (p.55)
[F2] (TVA Env) Setting the TVA envelope (p.56)
Pressing [F5] (LFO&Ctl)
[F1] (LFO 1) Modulating sound with vibrato and tremolo (p.57)
[F2] (LFO 2) Modulating sound with vibrato and tremolo (p.57)
[F3] (Control) Altering sound using controllers (p.58)
[F4] (Ctrl Sw) Setting how MIDI messages are received (p.59)
Pressing [F6] (Effects)
[F1] (General) Setting effects routing (p.60)
[F2] (EFX Prm) Setting EFX parameters (p.74)
[F3] (EFX Ctl) Modifying EFX using controllers (p.63)
[F4] (Chorus) Setting chorus parameters (p.64)
[F5] (Reverb) Setting reverb parameters (p.64)
Pressing [LOCAL/TX/RX]
[F1] (System) Setting Local Switch, Patch Rx-Ch and Patch Tx-Ch (p.90)
[F2] (Tx P.C) Transmitting Program and Bank Select numbers to external MIDI devices (p.182)
Pressing [SOUND LIST]
Displaying the Patch list (Sound List window) (p.27)
