Page 10 RS-500/600 Series Doors Part No 4801-5154 Rev 01-2017
*NOTE: When Brother Motor Option is used you can request that a RS-500
Door be wired for 115VAC or 230VAC. The RS-600 is wired for 230
VAC only. This must be done prior to purchase to ensure the door
has the correct brake rectifier installed.
3 Use of Equipment
The RS-500/600 Series Doors are motorized curtain enclosures for environmental control, ripening rooms,
docks/warehouses, car and truck washes, agricultural/horticultural, and coolers/freezers.
4 Physical Description
The RS-500/600 Series Doors are available with multiple features and options such as:
 Standard Door Sizes: Refer to Tables 1-4, RS-500/600 Series Standard Dimensions, Sections 9, 10, 11,
and 12.
 Operators: Manual Chain Hoist, Brother or Manaras Operator.
 Left/Right/Front Mounting: The Manaras Operators can be mounted on the left, right, or front. The
manual chain hoist can be mounted on the left or right side. The Operator Mounting Side must be selected
at the time of order.
 Left Mounting Only: The Brother motor can only be mounted on the left side, the associated controller, on
the right side.
 Manaras Operator Voltage Selection: 1/2 HP, Single Phase: 115V @ 8.6 amp, 230V @ 4.1 amp. 1/2 HP,
3 Phase: 208V @ 2.2 amp, 460V @ 1.1 amp. 1 HP, Single Phase: 115V @ 13.4 amp, 230V @ 6.7 amp. 1
HP, 3 Phase: 208V @ 3.4 amp, 460V @ 1.7 amp.
 RS-500 with Brother Motor - Controller Standard Input Voltage 115VAC (Must request 230VAC).
 RS-600 with Brother Motor - Controller Standard Input Voltage 230VAC.
 Operator Options: Remote receiver and transmitters, photo safety beams, leading edge switch.
 Accessories: Industry standard accessories can be added such as motion sensors, loop detectors, ceiling
pull switches, lock-out switches, other various types of switches, and door status / movement indicators
such as lights and buzzers.
 Windows: 32" high with width varying by width of door panel.
 Fabric & Fabric Colors: Frost, white, black, blue, red yellow, silver, tan, green, anti-static, and insect
screen.
NOTE: Certain options may only be available with specific operators. Refer to Section 40.5,
RS-500/600 Door Options and Accessories.
5 Differences between a RS-500 and RS-600 Series Door
RS-500 Series RS-600 Series
Speed (Brother Motor Option) Up to 18” Per Sec Up to 48” Per Sec
Speed (Manaras Motor) @8-11” Per Sec @16-22” Per Sec
Motor (Brother) 1/4hp 1/2hp
Motor (Manaras) 1/2hp GH 1hp GH
Drive Pipe 2 ½ inches 6 inches
Head Unit Small Large
*Standard Controller Input Voltage 115VAC 230VAC
(Brother Motor Option)
