Part No 4801-5154 Rev 01-2017 RS-500/600 Series Doors Page 39
23.5 Preparation for Operation
Refer of the RollSeal SC-325 and SC-650 Controller Manual (4801-5156) for more information on Controller
Settings.
Note: If you detect any problems, STOP. Disconnect electrical power. Contact your
distributor for assistance.
1. Insert fuse in Control.
2. Apply 115VAC power to Control and turn Control toggle switch on.
3. Set the Open and Close Limits:
1. Depress the Mode button (●) for at least 5 seconds. P1 (Close Time Delay) will be then be
displayed in the Display Indicator.
2. Depress and release the Mode button until PS1 (Change Program Limits) is displayed.
3. Depress Up ( ) until “yes” is displayed.
4. Depress the Mode button again (●). PS2 (Set Open Limit) will be displayed.
5. The door will proceed to the open limit and then stop. Once the door stops, adjust open limit
using the Up () or Down ( ) buttons until open limit is satisfactory.
6. Depress the Mode button (●) again. PS3 (Set Closed Limit) will be displayed.
7. The door will proceed to the closed limit and then stop. Once door stops, adjust this limit using
the Up () or Down ( ) buttons until the close limit is satisfactory.
8. Depress the Mode button (●) again and the controller will exit the programming mode and return
to displaying the actual position.
4. Press “Open” button on Outside Switch. If the Door is set to automatically close, door will time out
and automatically close if safety beams are clear. If the Door is set to manually close, press “Close”
button on Outside Switch and door should close.
5. Press “Open” (and “Close” if required) a couple times to insure proper operation.
6. Repeat steps 4 and 5 for Inside Switch.
7. Verify Safety Beams reverse door when blocked during closing.
8. Verify Leading Edge Switch is operational.
9. Verify that Warning Light and Egress Buzzer (if applicable) are functioning properly.
10. Ensure Safety Pull Hook for Egress and Pull Hook Tether are mounted inside cooler and Manual
Crank Handle for motor is mounted outside.
The door is now ready for operation.
