Page 14 RS-500/600 Series Doors Part No 4801-5154 Rev 01-2017
RS-500
Door
Height
B C
In. cm In. cm
7' (H)
84
213
104 11/16 266
7' 6" (H)
90
229
110 11/16 281
8' (H)
96
244
116 11/16 296
9' (H)
108
274
128 11/16 327
10' (H)
120
305
140 11/16 357
11' (H)
132
335
152 11/16 388
12' (H)
144
366
164 11/16 418
9 RS-500 Series Door (Brother Motor)
See Section 7 for Ratings and Specifications.
Motor must be connected through Controller.
TABLE 1 RS-500 Door Standard Dimensions:
WIDTH Related Dimensions HEIGHT Related Dimensions
RS-500
Door
Width
A D E
In. cm In. cm In. cm
4' (W)
48
122
64 3/8
164
82 5/16
209
5' (W)
60
152
76 3/8
194
94 5/16
240
6' (W)
72
183
88 3/8
225
106 5/16
270
6' 6" (W)
78
198
94 3/8
240
112 5/16
286
7' (W)
84
213
100 3/8
255
118 5/16
301
8' (W)
96
244
112 3/8
285
130 5/16
331
9' (W)
108
274
124 3/8
316
142 5/16
362
10' (W)
120
305
136 3/8
346
154 5/16
392
11' (W)
132
335
148 3/8
377
166 5/16 423
12' (W)
144
366
160 3/8
407
178 5/16
453
NSF Certified Doors are equipped
with Left mount Brother operators,
Smart Controller, and Magnetic
Track Sealing System
