Page 12 RS-500/600 Series Doors Part No 4801-5154 Rev 01-2017
7 Ratings and Specifications
RS-500/600 Series (Brother Motor)
RS-500 Doors
Part Number 6607-8057 6607-8056 6607-8058 6607-8060 6607-8061
Model Number SC-325-V01-115 SC-325-V02-0 SC-325-V01-115-W01
SC-325-V01-115-
PLUS
SC-325-V01-230-
PLUS
Power Supply 115 VAC or 230 VAC 50/60 Hz Single Phase
115 VAC or
230 VAC
50/60 Hz
Single Phase
230 VAC
50/60 Hz
Single Phase
Temperature
Range
32°F - 115°F (0°C – 46°C)
Inputs
10 Amps @ 115 VAC Single Phase or
6 Amps @ 230 VAC Single Phase
10 Amps @
115 VAC
Single Phase
6 Amps @
230 VAC
Single Phase
Outputs 230 VAC Three Phase 1/4 H.P.
Drive Setting Version 01 Version 02 Version 01 Version 01 Version 01
Factory Preset
Voltage Switch
& Jumper
115 VAC 230 VAC
Switch &
Warning Wires
with Conduit
N/A Switch Wiring Option
Optional Condensation Management System
DOOR MOTOR: 230 VAC Three Phase, ¼ hp
CONDENSATION MANAGEMENT SYSTEM (CMS): Voltage Rating 230 VAC ± 10% 50/60 Hz
Blower 135 Watt
Heater 1200 Watt
Total Current: 6.0 A @ 230 VAC (Typical)
9.0 A @ 230 VAC (Max.)
RS-600 Doors
Part Number 6607-8100 6607-8101 6607-8102 6607-8103
Model Number SC-650-V01-0 SC-650-V02-0 SC-650-V01-W01-PLUS SC-650-V02-W01-PLUS
Power Supply 230 VAC 50/60 Hz Single Phase
Temperature Range 32°F - 115°F (0°C – 46°C)
Inputs 8 Amps @ 230 VAC Single Phase
Outputs 230 VAC Three Phase 1/2 H.P.
Drive Setting Version 01 Version 02 Version 01 Version 02
Factory Preset Voltage
Switch & Jumper
230 VAC
Switch & Warning Wires
with Conduit
N/A Switch Wiring Option
NSF Certified Doors are equipped
with Left mount Brother operators,
Smart Controller, and Magnetic
Track Sealing System

RollSeal RS-600 Series Specifications

General

Brand	RollSeal
Model	RS-600 Series
Category	Garage Door Opener
Language	English
