3.3 Laying brake hoses
The brake hoses can be routed through the headset and installed in the frame. The front brake hose must be routed
through the headset on the non-drive side and the rear brake hose on the drive side (A). To fit the front brake hose, we
recommend fixing it to the steerer tube slightly above the opening in the steerer tube using adhesive tape (B).
The rear brake hose can be routed through the supplied foam tube to prevent rattling while riding. The foam tube can be
pushed over the head tube into the frame before the hose is laid. Additional fixing is not required. Make sure that the rear
brake hose is routed through the bottom bracket shell above the bottom bracket (C).
Follow the brake manufacturer's instructions for shortening, fitting and bleeding the brake.
A
BC
Brake hose front wheel
Brake hose rear wheel
