3.8 Installing seat post and saddle
DANGER
Raising the seat post below the minimum insertion mark may cause accidents or damage!
If the seat post is not inserted to the minimum insertion mark, it may break or damage the frame.
• The seat post must not be raised further than the limit mark!
• When cutting down the seat post, the original minimum insertion mark is no longer valid. Make sure to insert the
seat post at least 10 cm into the frame.
NOTE
Exceeding the maximum insertion mark may cause damage to the frame!
The insertion depth of the frame is limited. The seat post must not be inserted all the way down during riding.
4
7 Nm
1. Slide the cover upwards.
2. Open the clamp bolt. ATTENTION: Do not unscrew the bolt completely!
3. Carefully slide the seat post into the seat tube until you have reached the desired saddle height.
4. Tighten the clamp bolt to a torque of 7 Nm and slide the cover downwards.
5. Get on your bike and check whether the seat post height is right.
NOTE: If the post is completely removed from the frame, the parts of the seat post clamp should be held so that they
cannot fall into the frame.
