5. Technical details
Bottom bracket Pressfit BB86
Front wheel axle 12 x 100 mm
Rear wheel axle 12 x 142 mm
Brake mount front wheel Flat Mount 140 mm
Brake mount rear wheel Flat Mount 140 mm Note that the chain stays are 20 mm thick when selecting the
fixing bolt for the brake calliper (see also “3.6 Mounting the brake” on page 31).
Ø Brake disc Front and rear wheel: 140 mm, with use of an adapter max. 160 mm.
When using a 140 mm disc, check the installation space of the brake calliper.
Seat post Ø D-shape
max. tyre width700 x 32c
max. chainring size 54/40
Bottle Cages 2
5.1 Torques
5.2 Spare parts and accessories
At https://www.rosebikes.com/manuals, "Frame Details" are available for each bike model.
Here you will find all spare parts, torque values and other specific details for your bike.
Scan this QR code to go directly to the overview page of operating instructions.
6 - 8 Nm*
15 Nm
15 Nm
7 Nm
6 - 8 Nm*
2 Nm
5 - 7 Nm*
12 Nm
*please see the manufacturer’s instructions
