Rosemount 248 - Page 55

Reference Manual
00809-0100-4825, Rev BB
August 2005
A-9
Rosemount 248
Examples of 248 Transmitter and Sensor Assemblies with Thermowells
Tubular Thermowell and
DIN Plate Style Sensor
Barstock Thermowell and
DIN Plate Style Sensor
Barstock Thermowell, Nipple-Union Extension,
and
1
/2-in. NPT Spring Loaded Sensor
* 80 (3.2) for Class 900 flanges and larger
N = Extension Length, U= Thermowell Immersion Length, Dimensions are in millimeters (inches)
SEE ORDERING TABLES FOR MORE ASSEMBLY OPTIONS
248C Configuration Interface
Option 1: HART Interface Box
N
U
25 (1.0)
BUZ Connection Head
N
U
40 (1.6)
60 (2.3)
Connection Head
U
N
60 (2.3)*
Universal Head
SENSORS_0000B01E, 0000C01C, 0000A01I
On
O
f
f
+
S
ee warnings on back label
0.61 m (2 ft.)
Configuration Leads
38 (1.5)
1.83 m (6 ft.) Ribbon
84 (3.3)
114 (4.5)
248\3300A01A
