Reference Manual
00809-0100-4825, Rev BB
August 2005
Rosemount 248
A-8
DIMENSIONAL
DRAWINGS
248R Railmount Transmitter 248H Headmount Transmitter
(enlarged)
Dimensions are in millimeters (inches)
Enclosures
Connection Head
BUZ and Polypropylene Heads
(option codes B and C)
and Mini SST Head (option code S)
Universal Head
(1)
(option codes H and U)
(1) A “U” Bolt is shipped with each universal head unless a sensor is ordered assembled to the enclosure. However, since the head can be integrally mounted
to the sensor it may not need to be used.
123.5 (4.86)
95.25
(3.75)
25.9
(1.02)
48.77
(1.92)
44 (1.7)
33 (1.3)
12.9 (0.51)
24.5
(0.97)
104
(4.09)
100
(3.93)
78
(3.07)
Approval Label
84 (3.331)
118 (4.65)
95.35
72 (2.84)
95
(3.74)
96 (3.76)
112 (4.41)
SST “U” Bolt
Mounting,
2-inch Pipe
Approval
Label
75
(2.93)
