Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
103
Specifications and Reference Data
Transmitter housing style Material
Conduit entry
size
D 1-7
1L PlantWeb housing
SST G
1
/2 • •
2C Junction Box housing
Aluminum G
1
/2 • —
2G
Junction Box housing with output for remote display
and interface
Aluminum G
1
/2 • —
Performance class
(14)
3051S MultiVariable SuperModule, measurement types 1, 2, 5, and 6
• •
3
(15)
Ultra for Flow: up to 0.75% flow rate accuracy, 14:1 flow turndown, 10-yr stability,
limited 12-yr warranty
• • ★
5 Classic MV: up to 1.10% flow rate accuracy, 8:1 flow turndown, 5-yr stability
— • ★
3051S Single Variable SuperModule, measurement types 3, 4, 7, and D
• •
1
Ultra: up to 0.90% flow rate accuracy, 8:1 flow turndown, 10-yr stability, limited 12-yr
warranty
• — ★
2 Classic: up to 1.40% flow rate accuracy, 8:1 flow turndown, 5-yr stability
• — ★
3
(15)
Ultra for Flow: up to 0.75% flow rate accuracy, 14:1 flow turndown, 10-yr stability,
limited 12-yr warranty
• • ★
Wireless Options (Requires option code X and wireless PlantWeb housing)
Update rate, operating frequency, and protocol D 1-7
WA User configurable update rate • — ★
Operating Frequency and protocol
3 2.4 GHz DSSS, IEC 62591 (WirelessHART) • — ★
Omni-directional Wireless Antenna
WK External antenna • — ★
WM Extended range, external antenna • — ★
WN High-Gain, remote antenna • —
SmartPower
(16)
1 Adapter for Black Power Module (I.S. Power Module sold separately) • — ★
Table 2. Rosemount 3051SFC Compact Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
