Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
104
Specifications and Reference Data
Other Options (Include with selected model number)
Extended product warranty D 1-7
WR3 3-year limited warranty
• • ★
WR5 5-year limited warranty
• • ★
Installation accessories
A
ANSI alignment ring (150#) (only required for 10-in. (250 mm) and 12-in. (300mm)
line sizes)
• • ★
C
ANSI alignment ring (300#) (only required for 10-in. (250 mm) and 12-in. (300mm)
line sizes)
• • ★
D
ANSI alignment ring (600#) (only required for 10-in. (250 mm) and 12-in. (300mm)
line sizes)
• • ★
G DIN alignment ring (PN 16) • • ★
H DIN alignment ring (PN 40) • • ★
J DIN alignment ring (PN 100) • • ★
B JIS alignment ring (10K) • •
R JIS alignment ring (20K) • •
S JIS alignment ring (40K) • •
Remote adapters
E Flange adapters 316 SST (
1
/2-in. NPT) • • ★
High temperature applications
T Graphite valve packing (T
max
= 850 °F) • •
Flow calibration
WC
(17)
Discharge coefficient verification (3 point) • •
WD
(18)(19)
Discharge coefficient verification (full 10 point) • •
Pressure testing
P1 Hydrostatic testing with certificate • •
Special cleaning
P2
(20)
Cleaning for special processes • •
PA Cleaning per ASTM G93 level D (section 11.4) • •
Table 2. Rosemount 3051SFC Compact Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
