Rosemount 3051SFA - Page 261

Reference Manual
00809-0100-4809, Rev DA
Appendix B: Product Certifications
September 2015
253
Product Certifications
®
DR.
SIZE
C
TITLE
BOULDER, COLORADO
DRAWING NO.
APPROVAL
SPECIALS
TAGGING
DRAWING
*ALL DIMENSIONS ARE NOMINAL
AND ARE FOR REFERENCE ONLY
*UNLESS OTHERWISE SPECIFIED
DIMENSIONS IN INCHES (MM)
TYPE I
SHEET:
of
SCALE
: NONE
REVISION
ECO NO.
APP'D
DATE
REVISION TABLE
DESCRIPTION
5.62 [142,7]
FOR ALL
LINE SIZES
8.25 [210] BOTH OPEN MAX
7.75 [197] BOTH CLOSED MIN
6.25 [159] OPEN MAX
6.00 [152] CLOSED MIN
B
SEE TABLE 1
1.125 [28,58]
P DEEGAN
12/13/11
S IFFT
12/27/11
00405-1001
2
7
DIMENSIONAL DRAWING MODEL 405 COMPACT FLOWMETER
2/24/14JSDSI1051961AQ
REMOVE BETA CALLOUT FROM NOTE 6
DP PRIMARY
COMPONENTS
NOTE: ALL INFORMATION TYPICAL TO
ALL TYPES OF 405 MODELS UNLESS
OTHERWISE NOTED
TEMPERATURE PORT (405C & P ONLY)
TEMPERATURE PORT 1/4" NPT PLUG (405C & P ONLY)
ISOLATION VALVE
2X 1/4" NPT VENTS (405C & P ONLY)
ISOLATION
VALVE
EQUALIZER
VALVE
ISOLATION VALVE
1/4" NPT PLUG FOR RTD CONNECTION (405A ONLY)
TEMPERATURE PORT PLUG (405A ONLY)
ISOLATION
VALVE
EQUALIZER
VALVE
NOTE: DIMENSIONS ARE TYPICAL TO
ALL TYPES OF 405 MODELS
WITH STANDARD VALVES
FLOW
FLOW
