Rosemount 3051SFA - Page 262

Reference Manual
00809-0100-4809, Rev DA
Appendix B: Product Certifications
September 2015
254
Product Certifications
®
DR.
SIZE
C
TITLE
BOULDER, COLORADO
DRAWING NO.
APPROVAL
SPECIALS
TAGGING
DRAWING
*ALL DIMENSIONS ARE NOMINAL
AND ARE FOR REFERENCE ONLY
*UNLESS OTHERWISE SPECIFIED
DIMENSIONS IN INCHES (MM)
TYPE I
SHEET:
of
SCALE
: NONE
REVISION
ECO NO.
APP'D
DATE
REVISION TABLE
DESCRIPTION
6.20 [157] FOR 2051CFCDC/P 6.55 [166] FOR 3051CFCDC/P
7.70 [196] FOR 3051SFC_C/P
F
10.4 [264] MAX OPEN
10.2 [258] MIN CLOSED
3051S ONLY
10.25 [261] MAX OPEN
10.0 [254] MIN CLOSED
3051S ONLY
7.03 [179] FOR 2051CFCDA 7.38 [188] FOR 3051CFCDA
8.53 [217] FOR 3051SFC_A
P DEEGAN
12/13/11
S IFFT
12/27/11
00405-1001
3
7
DIMENSIONAL DRAWING MODEL 405 COMPACT FLOWMETER
2/24/14JSDSI1051961AQ
REMOVE BETA CALLOUT FROM NOTE 6
3051SFC
LINE SIZE F IN(mm)
1/2" 5.3 (134)
1" 5.0 (127)
1-1/2" 4.5 (115)
2" 5.9 (150) 3" 5.2 (132) 4" 4.6 (116) 5" 7.2 (184) 6" 6.7 (171) 8" 5.8 (148)
10" 6.7 (170) 12" 5.7 (144)
DIRECT MOUNT TYPE
CONNECTION OPTIONS
