Rosslare AC-215 - Figure 1: Axtrax AS-525 and AC-215 System

Introduction
10 AC-215 Installation Manual
Figure 1: AxTrax™ AS-525 and AC-215 System
AxTrax™
Software
RS-485/232
Converter
AC-215
Single Door
Up to 32 ACUs
AC-215
AC-215
Single Door
AC-215
Double Door
RS485
RS232
RS485
RS485
Door
Monitor
Door
2
Maglock
Exit
button
Reader
Door
4
Exit button
Reader, Keypad,
and Door Release
2 readers
for
Reader In
and
Reader
Out
Door
3
Door 1
Reader,
Keypad,
and Door
Release
