Power Supply Specifications
42 AC-215 Installation Manual
C. Power Supply Specifications
ACU uses the PS-14 power supply.
Transformer
AC Transformer
120/220 VAC, 16 VAC 2.5 A (40 VA), Class 2
(not included)
PS-14 Power Supply Specifications
Input Voltage
16 VAC, 2.5 A
From Transformer Backup
Battery Charger
12 VDC, 300 mA
From Transformer Output
Voltage 1
13.8 V
Access control panel Output
Voltage 2
12 VDC, 0.5 A
From ACU (to lock strike)
Output Voltage 3
12 VDC, 1.5 A
Power Supply Indication
Tamper Output (open collector)
Indicates faulty power
Power LEDs
Power In (AC) Green LED1
Main power
Power Out (DC) Red LED2
Low voltage
Charger (BAT) Red LED3
Backup battery low voltage
