Introduction
12 AC-215 Installation Manual
1.1.3.1 Single Door Controller
This access type has two readers – In or Out
Outputs Inputs
Door lock strike Release to exit
Auxiliary output Door monitor input
Alarm output Tamper input
General purpose output General purpose input
1.1.3.2 Double Door Controller
This access type has two readers – In or Out
Outputs Inputs
Door 1 lock strike Release to exit door1
Door 1 alarm output Door 1 monitor input
Door 2 lock strike Release to exit door 2
Door 2 alarm output Door 2 monitor input
1.2 Software
The AxTrax™ AS-525 software is user-friendly and intuitive. Its graphic
interface is used to define settings, which are downloaded to the ACU and
event logs which are uploaded to the PC to generate reports. A single server,
which communicates to and from the ACU, can serve unlimited network
clients.
The system’s database is saved in the server. The database can be set to
backup and can import/export previous configurations. Clients are able to
modify the database, for example, define new employees and their access
permissions.
The software enables features to be added as and when they are required. The
modular software enables the user interface to be as powerful and strong as
required and yet remains simple to use. The software can be set for automatic
backup on a periodic basis.
AxTrax™ AS-525 can be run on Windows 98, 2000, NT and XP.
