Inputs and Outputs
AC-215 Installation Manual 17
3.1.11 Keypad
Two keypads can be alternatively connected to the ACU on Reader1 and
Reader2 terminals. The following should be defined:
Single door controller
Door 1 Keypad – Reader 1 IN/OUT
Keypad – Reader 2 IN/OUT
Double door controller
Door 1 Keypad – Reader 1 IN/OUT
Door 2 Keypad – Reader 2 IN/OUT
The keypad type must be a Rosslare format keypad.
A keypad has to be connected for any reader mode that requires PIN code
entries, such as Card or PIN, PIN only or Card and PIN (Secured mode).
