AC-425 Hardware Settings
30 AC-425 Hardware Installation and User Manual
Connectors Description Setup
Readers Reader1 (Door1 IN/OUT)
Reader2 (Door2 IN/OUT)
Reader3 (Door3 IN/OUT)
Reader4 (Door4 IN/OUT)
Two readers per door with 8 readers (MD-D04):
Outputs Door1 Lock output (OUT 1)
Door2 Lock output (OUT 2)
Door3 Lock output (OUT 5)
Door4 Lock output (OUT 6)
Inputs Door1 Request to exit (IN 1)
Door1 monitor input (IN 3)
Door2 Request to exit (IN 2)
Door2 monitor input (IN 4)
Door3 Request to exit (IN 5)
Door3 monitor input (IN 7)
Door4 Request to exit (IN 6)
Door4 monitor input (IN 8)
Readers Reader1 (Door1 IN/OUT)
Reader2 (Door2 OUT/IN)
Reader3 (Door1 IN/OUT)
Reader4 (Door2 OUT/IN)
Reader5 (Door3 IN/OUT)
Reader6 (Door4 OUT/IN)
Reader7 (Door3 IN/OUT)
Reader8 (Door4 OUT/IN)
One reader per door with 8 readers (MD-D04)
Outputs Door1 Lock output (OUT 1)
Door2 Lock output (OUT 2)
Door3 Lock output (OUT 3)
Door4 Lock output (OUT 4)
Door5 Lock output (OUT 5)
Door6 Lock output (OUT 6)
Door7 Lock output (OUT 7)
Door8 Lock output (OUT 8)
