Input and Output Connections
AC-425 Hardware Installation and User Manual 27
4.4 Card Readers and Keypads
Each access control panel can be connected to a maximum of four readers or 8
readers when using MD-D04. There are three available types of reader:
 Card readers
 Keypads
 Dual keypad card readers
A keypad is required for any reader mode that requires PIN code entries, such
as "Card or PIN", "PIN Only" or "Card and PIN (Secured mode)".
When connecting a reader, the following should be defined:
Scenario Setting
Two readers per door Door 1 – Reader 1 IN/OUT
Door 1 – Reader 3 IN/OUT
Door 2 – Reader 2 IN/OUT
Door 2 – Reader 4 IN/OUT
One readers per door Door 1 – Reader 1 IN/OUT
Door 2 – Reader 2 IN/OUT
Door 3 – Reader 3 IN/OUT
Door 4 – Reader 4 IN/OUT
When using the MD-D04, the following should be defined:
Scenario Setting
Two readers per door: Door 1 – Reader 1 IN/OUT
Door 1 – Reader 3 IN/OUT
Door 2 – Reader 2 IN/OUT
Door 2 – Reader 4 IN/OUT
Door 3 – Reader 5 IN/OUT
Door 3 – Reader 7 IN/OUT
Door 4 – Reader 6 IN/OUT
Door 4 – Reader 8 IN/OUT
One readers per door: Door 1 – Reader 1 IN/OUT
Door 2 – Reader 2 IN/OUT
Door 3 – Reader 3 IN/OUT
Door 4 – Reader 4 IN/OUT
Door 5 – Reader 5 IN/OUT
Door 6 – Reader 6 IN/OUT
Door 7 – Reader 7 IN/OUT
Door 8 – Reader 8 IN/OUT
