Introduction
8 AC-425 Hardware Installation and User Manual
1. Introduction
In this manual, unless otherwise stated, “AC-425” refers to both the regular
AC-425 and the AC-425IP moels.
The AC-425 access control panel is a state-of-the-art networked access
controller, employing the latest technology to meet the requirements of the
market.
The state-of-the-art dual/quad door AC-425 networked access controller is the
backbone of medium scale security systems handling up to 30,000 users and
8184 doors.
Each AC-425 access control unit (ACU) supports four readers (In/Out) of
various formats including standard Wiegand 26-bit. Installations can also have
one reader per door.
The AC-425 comes in two models:
 AC-425 – standard model
 AC-425IP – supports TCP/IP connection
Driven by Rosslare’s powerful, flexible and easy-to-use AxTraxNG™ software,
the system provides an ideal, modular and expandable solution for commercial
and institutional needs. It provides seamless integration with Rosslare's range
of RFID proximity, PIN, Proximity & PIN, smartcard and biometric readers with
Rosslare’s selection of RFID credentials.
The AC-425 is ready for installation with a mountable & lockable metal
enclosure integrated with transformer, power supply/charger, sounder and
control board.
Using onboard RS-232/485, Ethernet TCP/IP (AC-425IP model only), multiple
local or remote sites, door sub-networks can connect to the AxTraxNG
Client/Server PC software running on Microsoft
®
Windows
®
98/ME &
NT/2000/XP/7 operating systems.
The AC-425 consists of the following components:
 AC-425 controller board
 Panel enclosure
 PS-33 power supply
 Power transformer
 4 x 2.2 kΩ and 4 x 8.2 kΩ resistors for the supervised inputs
