AC-425 Hardware Settings
AC-425 Hardware Installation and User Manual 29
5. AC-425 Hardware Settings
Each AC-425 panel controls an entrance. The behavior of the panel is
controlled by DIP switch settings.
Select the appropriate DIP switch setting to operate the panel as either a single
door, a double door, or four doors (see Section 5.3).
Access control panels, configured as either single door or double door
controllers, have two readers, IN or OUT. Access control panels configured
with the MD-D04 expansion as either double door or four-door controllers
have four readers.
Table 1: Possible Hardware Settings
Connectors Description Setup
Two readers per door:
Outputs Door 1 Lock output (OUT 1)
Door 2 Lock output (OUT 2)
General purpose output (OUT 3)
General purpose output (OUT 4)
Inputs Door 1: Request to exit (IN 1)
Door monitor input (IN 3)
Door 2: Request to exit (IN 2)
Door monitor input (IN 4)
Readers Reader1 – Door1 Door Entry or Exit
Reader2 – Door2 Door Exit or Entry
Reader3 – Door1 Door Entry or Exit
Reader4 – Door2 Door Exit or Entry
One reader per door:
Outputs Door1 Lock output (OUT 1)
Door2 Lock output (OUT 2)
Door3 Lock output (OUT 3)
Door4 Lock output (OUT 4)
Inputs Door1 Request to exit (IN 1)
Door2 Request to exit (IN 2)
Door3 Request to exit (IN 3)
Door4 Request to exit (IN 4)
