Rosslare AC-425 User Manual

AC-425 Hardware Settings
34 AC-425 Hardware Installation and User Manual
Address Switch 4 Switch 5 Switch 6 Switch 7 Switch 8
19 On Off Off On Off
20 On Off Off On On
21 On Off On Off Off
22 On Off On Off On
23 On Off On On Off
24 On Off On On On
25 On On Off Off Off
26 On On Off Off On
27 On On Off On Off
28 On On Off On On
29 On On On Off Off
30 On On On Off On
31 On On On On Off
32 On On On On On
The AC-425 panel address is defined in the AxTraxNG software.
The DIP switch and the software must be set to the same address.

Rosslare AC-425 Specifications

General

Brand	Rosslare
Model	AC-425
Category	IP Access Controllers
Language	English
