Rosslare AC-F44 User Manual

Technical Specifications
14 AC-F/G4x Series Installation and Programming Manual
2. Technical Specifications
AC-F43
AC-F44
AC-G43
AC-G44
Input
Voltage
VDC 12 to 24 VDC
VAC 16 to 24 VAC
Maximum Input Current
(12 VDC)
125 mA 160 mA 125 mA 160 mA
Standby Input Current
(12 VDC)
75 mA 95 mA 75 mA 95 mA
Maximum Relay Current 2 A
REX Input Normally Open (dry contact)
Aux. Input Normally Open (dry contact)
Max. Proximity Read
Range*
N/A 75 mm
(3.0 in.)
N/A 80 mm
(3.2 in.)
Proximity Modulation N/A
ASK at 125
kHz
N/A
ASK at 125
kHz
Proximity Card
Compatibility
N/A
26 Bits EM
cards
N/A
26 Bits EM
cards
LED Indicators Two 3-colored LED (Mode and Door)
Operating Temp. Range -30°C to 65°C (-22°F to 150°F)
Operating Humidity
Range
0 to 95% (non-condensing)
Outdoor Usage Weather resistant, meets IP65, epoxy-potted

Rosslare AC-F44 Specifications

General

Brand	Rosslare
Model	AC-F44
Category	Controller
Language	English
