Rosslare AC-F44 User Manual

Programming
52 AC-F/G4x Series Installation and Programming Manual
5.11
Setting the Backlight Behavior
The controller allows you to define the way the unit’s backlight
works.
To set the backlight behavior:
1.
Enter Programming mode.
2.
Press 6 to enter Menu 6.
The left LED flashes green.
3.
Enter one of the following codes:
 5000 – Backlight off
 5100 – Backlight on (default)
 5200 – Backlight is off, activates for 10 seconds when a
key is pressed, after which it dims until off
 5300 – Backlight is dimmed, activates for 10 seconds
when a key is pressed
, after which it returns to a dimmed
level
Green
Green
Green

Rosslare AC-F44 Specifications

General

Brand	Rosslare
Model	AC-F44
Category	Controller
Language	English
