Technical Specifications
8
2. Technical Specifications
Electrical Characteristics
Operating Voltage Range
Typical: 9 to 12 VDC (2 A)
Max: 24 VDC
Input Current
Standby: 0.2 A max
Read: 1.2 A max
Credential Read Distance*
0.5 to 12 m (1.6 to 39.4 ft) (adjustable)
Transmission Protocol
Wiegand 26-Bit (default)
Wiegand 32-Bit
Wiegand 34-Bit
Wiegand 40-Bit
Wiegand 56-Bit
Wiegand 64-Bit
OSDP
Custom
Maximum Cable Distance
150 m (492 ft) with 18” AWG cable
Frequency
AY-U920BT-US: 902–928 MHz (America)
AY-U920BT-EU: 865–868 MHz (Europe)
Modulation Type
ASK
Read Sensitivity
Dual polarization read mode
Cards and Tags
• EPC GEN2 (ISO18000-6C) Tags
• BLE-ID soft credentials
* Measured using a Rosslare proximity card or equivalent.
Environmental Characteristics
Operating Temp. Range
-20°C to 60°C (-4°F to 140°F)
Operating Humidity Range
0 to 95% (non-condensing)
Suitable for outdoor use (IP 54)
Physical Characteristics
Height x Width x Depth
36.5 x 36.5 x 3.2 cm (14.4 x 14.4 x 1.3 in.)
Weight
2.8 kg (6.2 lb)
