Controller Operation
AYC-F/Gx4 Series Installation and Programming Manual 43
3. Construct a code using the following
instructions:
 Second digit (Auxiliary Mode)
In addition to the Lock Strike Relay and Lock Strike REX, the
unit features an Auxiliary Input. The Auxiliary mode defines
the function of the Auxiliary Input.
 Third and fourth digits (Auxiliary Setting)
Each of the Auxiliary modes has a 2-digit setting that affects
how the Auxiliary mode functions (Table 5).
You hear three beeps.
The system returns to Normal mode.
Table 5: Quick Reference Guide for Auxiliary Mode Setting
Aux.
Mode
Aux. Input
Function
Aux.
Output
Activated
by
Aux.
Relay
Aux.
Settings
(in seconds)
0 AUX REX Valid code or
AUX REX
N.O. 01 to 99 Aux.
relay release time
1 Normal/Secure
switch
Valid code N.O. 01 to 99 Aux.
relay release time
2 Normal/Secure
switch
Star button (*)
N.O. 01 to 99 Aux.
relay release time
3 Normal/Secure
switch
Tamper event N.C. 01 to 99 Aux.
relay release time
4 Normal/Secure
switch
Direct shunt N.O. 01 to 99 Shunt
time
5 Door Monitor Shunt N.C. 01 to 99
Maximum shunt
time
6 Door Monitor Forced door N.C. 01 to 99 Forced
delay
Green
